Double Station Heat Presses

▶ Model No.: TSLE-20 / TSLE-24
▶ Machine Type: Automatic, Dual Station, Precise Alignment
▶ Controller: GY-13 Large Touchscreen Panel
▶ Platen Size: 16"x20"/16"x24" (40x50cm/40x60cm)
▶ Under Plate: Left & Right Slider, Quick-change
▶ Air Compressor Required: No
▶ Alignment: ProAlign Vision™ HD Projection System
▶ Software: SmartFit Studio™ Alignment Software & Tablet Bundle
▶ Voltage: 110V/ 220V
▶ Power: 1.7KW/ 1.8KW
▶ Packing Size: 123x106x170cm
▶ Gross Weight: 401kg/410kg (Wooden Package)

▶ Model No.: TSLE-20 (40x50cm) / TSLE-24 (40x60cm)
▶ Machine Type: Automatic, Dual Station
▶ Platen Size: 16"x20"/16"x24" (40x50cm/40x60cm)
▶ Under Plate: Left & Right Slider
▶ Controller: GY-13 Large Touchscreen Control Panel
▶ Air Compressor Required: No
▶ Voltage: 110V/ 220V
▶ Power: 1.7KW/ 1.8KW
▶ Packing Size: 123x106x170cm
▶ Gross Weight: 358kg/365kg (Wooden Package)

▶ Model No.: XPDS-20
▶ Machine Type: Automatic, Dual Station
▶ Platen Size: 15"x15"/16"x20" (38x38cm/40x50cm)
▶ Under Plate: 8 Shapes Quick-change lower platen
▶ Controller: GY-08 Digital Time & Temp. Control
▶ Air Compressor Required: Yes
▶ Voltage: 120V/ 220V
▶ Power: 1.6KW/ 1.8KW
▶ Packing Size: 102x115x150cm/102x115x150cm
▶ Gross Weight: 291kg/301kg (Wooden Package)

▶ Model No.: PSTM-40/ PSTM-48/ PSTM-68
▶ Machine Type: Double Station, Individual Plug-In Heat Tubes
▶ Platen Size: 80x100cm/100x120cm/120x170cm
▶ Platen Size: 32"x40"/40"x48"/48"x68"
▶ Controller: GY-06 Digital Time & Temp. Control
▶ Printable Articles: Up to 20mm Thickness
▶ Air Compressor Required: Yes
▶ Voltage: 220V 1phase/ 220V 3phase/ 380V 3phase
▶ Power: 5.1KW/ 7.5KW/ 9KW                               >>

▶ Model No.: ASTM-40/ ASTM-48/ ASTM-64
▶ Machine Type: Automatic, Double Station
▶ Platen Size: 80x100cm/100x120cm/100x160cm
▶ Platen Size: 32"x40"/40"x48"/40"x64"
▶ Controller: GY-06 Digital Time & Temp. Control
▶ Printable Articles: Up to 20mm Thickness
▶ Air Compressor Required: Yes
▶ Voltage: 220V 1phase/ 220V 3phase/ 380V 3phase
▶ Power: 5.1KW/ 7.5KW/ 9KW                               >>

▶ Model No.: FSTM-48
▶ Machine Type: Semi-auto, Double Station
▶ Platen Size: 24"x48" (60x120cm)
▶ Controller: PLC Controller
▶ Printable Articles: Up to 50mm
▶ High Pressure: 8KG/CM²
▶ Air Compressor Required: 4.5kgf/c㎡
▶ Voltage: 220V 1phase/ 220V 3phase/ 380V 3phase
▶ Power: 5.4KW
▶ Gross Weight: 685KG
▶ Packing Size:199x162x170cm                      >>

▶ Model No.: DEMON 45
▶ Machine Type: Pneumatic, Dual Station
▶ Platen Size: 16"x20" (40x50cm)
▶ Under Plate: Quick Exchangeable
▶ Controller: GY-06 Digital Time & Temp. Control
▶ Printable Articles: Up to 50mm Thickness
▶ Air Compressor Required: Yes,1~3HP
▶ Voltage: 110V/ 220V
▶ Power: 1.6KW/ 1.8KW
▶ Packing Size: 115x112x160cm
▶ Gross Weight: 395kg (Wooden Package)

▶ Model No.: ASTM-24
▶ Machine Type: Auto-Shuttle, Double Station
▶ Platen Size: 16"x24" (40x60cm)
▶ Controller: GY-06 Digital Time & Temp. Control
▶ Printable Articles: T-shirts, multiple piece, banners
▶ Air Compressor Required: Yes
▶ Voltage: 110V/ 220V
▶ Power: 1.6KW/1.8KW                     >>

▶ Model No.: APDS-15/ APDS-20
▶ Machine Type: Air operated, Dual Station, Sliding
▶ Platen Size: 15"x15"(38x38cm)/ 16"x20"(40x50cm)
▶ Maximum Temp.: 225℃
▶ Power: 1.5KW-1.8KW
▶ Voltage: 120V/ 220V
▶ Certification: CE Approval
▶ Gross Weight: 151KG / 160KG
▶ Carton Size:  121x99x75cm              >>

▶ Model No.: Omega 1000
▶ Machine Type: Automatic, Double Station, Auto Swing
▶ Platen Size: 15"x20" (38x50cm)
▶ Controller:  GY-06 LED Digital Control
▶ Max. Air Supply: 6 bar max. (87 Psi)
▶ Compressed Air Consumption: 40Litres/min
▶ Power: 2.5KW
▶ Voltage: 230-240V
▶ Certification: CE Approval
▶ Gross Weight: 182KG
▶ Carton Size:  107x95x110cm              >>

▶ Model No.: TC-15A/ TC-20A/ TC-B
▶ Machine Type: Auto Release, Double-Station
▶ Platen Size: 15"x15"/ 16"x20"(38x38cm/ 40x50cm)
▶ Under Plate: Double, Left & Right Slider
▶ Controller: GY-06 Digital Time & Temp. Control
▶ Air Compressor Required: No
▶ Power: 1.6KW/ 1.8KW
▶ Voltage: 110v/ 220v
▶ Wooden Box Size: 113x91x82cm
▶ Gross Weight: 151kg (20A)

▶ Model No.: UHP-20M-D
▶ Machine Type: Auto Release, Double Station
▶ Platen Size: 15"x15"/ 16"x20" (38x38cm/ 40x50cm)
▶ Under Plate: Double, Silding
▶ Controller: GY-04 Digital Time & Temp. Control
▶ Air Compressor Required: No
▶ Voltage: 110v/ 220v
▶ Power: 1.6KW/ 1.8KW
▶ Wooden Box Size: 101x88x58cm
▶ Gross Weight: 95kg for 40x50
